A.C. CIRCUITS EXPERIMENT SET CHOKES, CAPACITORS & RESISTORS

  • EM0050-001

AC Circuits Experiment Set is used mainly for Trade School students where study of AC theory is required. It is a well ventilated enclosure which houses a set of heavy duty resistors, chokes and capacitors for voltages up to 240V.AC.

All items connect to 4mm terminals on the front panel that permit interconnection. All components are rated at 2 amps.

Work on Power Factor, electric motor theory and electrical efficiency can be performed using this equipment.

Our products are for use in Laboratory or Educational setting only
Use under appropriate supervision

Instruction Sheet
